Product Description
Details
Scanspeak 18W/4531G00 Mid Woofer - Revelator Range. Revelator midwoofers are famous for their Scanspeak Sliced Paper Cones, the slices are filled with damping glue. The effect is to reduce break-up nodes in the 7" cone, and give a midrange clarity and overall smooth frequency response which has made this top audiophile range uniquely successful.
Symmetrical Drive SD-1 Motor, Die-Cast Aluminum Chassis vented below spider.
Low Loss linear suspension, large ferrite magnet system and a high output.
Delivery is normally 7-10 working days if not in stock. Supplied in boxed matched pairs (2 units) only.
A Product Datasheet is available below.
Additional Information
Additional Information
| Scanspeak Range | Scanspeak Revelator |
|---|---|
| Nominal Impedance | 4 ohms |
| Nominal Power RMS | 70 W |
| Vas ( l) | 41.90 l |
| Nominal Free Air Resonance Fs | 33 Hz |
| Sensitivity (2.83V/1m) | 90 dB |
| Nominal Rdc | 4.2 ohm |
| Qes | 0.38 |
| Qms | 5.2 |
| Qts | 0.35 |
