SB Acoustics SB29RDC-C000-4 tweeter is an outstanding SB Acoustics Ferrite magnet tweeter, featuring high sensitivity, low distortion characteristics from the stabilised dome centre. This tweeter is renowned for a superb off-axis response and excellent extended highly linear response response. Highly regarded and used by several OEM manufacturers.
It has a proprietary stabilised coated fabric ring dome, 1.2” voice coil, Copper Cap pole piece, and a 104mm OD face plate. The rear chamber is specially designed to give a very low Fs (600 Hz) and reduce internal back reflections.
Superb value. For a smaller 72mm faceplate design with Neodymium magnet, see SB29RDNC-C000-4
Priced individually, supplied in pairs.
A Product Datasheet can be downloaded by clicking on the appropriate .pdf logo (where shown).
|Nominal Impedance||4 ohm|
|Nominal Power RMS||100W|
|Vas ( l)||-|
|Nominal Free Air Resonance Fs||600 Hz|
|Sensitivity (2.83V/1m)||93 dB|
|Nominal Rdc||3.00 ohm|
